We are a trusted manufacturer and supplier of high-quality AODD Pumps (Air Operated Double Diaphragm Pumps) designed for superior performance, durability, and chemical compatibility across a wide range of industries. These pumps are self-priming, run-dry capable, and engineered to handle a variety of fluids, including viscous, abrasive, and shear-sensitive liquids with ease.
Whether you need a pump for chemical processing, wastewater management, or food-grade operations, our range of AODD Pumps offers unmatched versatility and reliability.
AODD Pumps, short for Air Operated Double Diaphragm Pumps, are positive displacement pumps powered by compressed air. These pumps use two flexible diaphragms that move back and forth to draw in and discharge fluid. With no electricity required and excellent resistance to clogging, AODD Pumps are ideal for challenging pumping environments.
| Specification | Details |
|---|---|
| Pump Type | Air Operated Double Diaphragm (AODD Pump) |
| Material of Construction | Polypropylene, PVDF, Aluminum, SS304, SS316 |
| Diaphragm Material | Teflon (PTFE), Santoprene, Buna-N, EPDM, Viton |
| Max Flow Rate | Up to 1000 LPM (varies by model) |
| Max Solid Handling | Up to 6 mm (depending on model) |
| Suction/Discharge Port | ½” to 3” BSP/NPT/Flanged |
| Mounting | Floor / Skid / Wall Mountable |
| Explosion Proof | Yes, due to non-electric operation |
Our AODD Pumps are widely used in various industries due to their adaptability and robust design. Applications include :
With a commitment to quality, innovation, and after-sales support, we are recognized as one of the most reliable AODD Pumps manufacturers in India. Our product range complies with international standards and is tested under rigorous conditions to ensure top performance and durability.
We also offer customized AODD Pumps to suit your specific flow rate, temperature, and chemical compatibility needs. Our in-house team supports you with technical guidance, installation, and service backup.
